PVC material, NSF listed under 14/61 for both potable water and DWV applications
Maximum flow rate of 2.4 GPM at 80 PSI when fully open
All injection molded, rugged design and construction
Heavy-wall, custom-extruded gooseneck component for increased rigidity
Standard 3/8" female NPT inlet connection
Includes a Jaco 3/8" O.D. compression tube fitting
Removable serrated outlet barb fitting that accepts 1/4"-1/2" I.D. tubing
When removed, the barb tip leaves a 1/4" female NPT outlet for connecting to accessories and other fittings
Duraline control valve with all PTFE sealing:
Encapsulated PTFE shut-off seal provides an ideal construction geometry for keeping the PTFE in compression for constant on/off operation
Crevice-free with zero dead leg
Swivel union provides 360 degrees of rotation without the need to loosen the union
PVC: 180 PSI @ 72° Fahrenheit
Lab faucet body & components: Injection molded and extruded in PVC, meeting or exceeding FDA, USDA, and USP standards. Please contact us for further validation.
Duraline control valve seal & seat: The stem seal and encapsulated shut-off seal are machined from 100% virgin PTFE (Polytetrafluoroethylene).
