Features:
Flow rate: max flow rate of 2.4 GPM at 80 PSI, full open
FDA, USDA, and USP standard are either met and/or exceeded
All injection molded, rugged design and construction
Gooseneck component is heavy wall, custom extruded for increased rigidity
Materials: Unpigmented Natural Polypropylene (Profax)
Standard 3/8" female NPT inlet connection. Each faucet comes with Jaco 3/8" O.D. compression tube fitting
Removable serrated outlet barb fitting accepts 1/4"-1/2" I.D. tubing, leaves 1/4" female npt inlet when removed
Duraline control valve features all PTFE sealing; an encapsulated PTFE shut off seal provides an ideal construction geometry for keeping the PTFE in compression for constant on/off operation
Duraline control valve is crevice free with zero dead leg
Swivel union provides 360 degrees of rotation, the swivel union does not need to be loosened to operate swivel
Inlet connections:
3/8" Female NPT Standard Inlet; Polypro Jaco 3/8" O.D. x 3/8" Male NPT compression tube fitting is included with each faucet
Deck Panel Mounting:
Lab faucet assembly includes a 3" thru-deck nipple shank, ring nut, and casual water gasket
All assemblies require 1" diameter hole for mounting
Maximum deck thickness is 3"
Max Pressure Ratings:
PVC: 180 PSI @ 72° Fahrenheit
Materials of Construction:
Lab Faucet Body & Components: Injection molded and extruded in Natural Polypropylene. FDA, USDA, and USP standards are either met and/or exceeded, please contact us for further validation.
Duraline Control Valve Seal & Seat: The stem seal and encapsulated shut off seal are machined from 100% Virgin PTFE (Polytetrafluoroethylene).
